HSGQ-F100P
| Quantity: | |
|---|---|
F100P is a PoF single-port iron housing ONU for all-optical network solution, providing 1*G/EPON adaptive SC port, 1*GE LAN port, high-speed access, downlink 2.5Gbps, uplink 1.25bps; Plug & Play, OMCl support; PON port supports PoF optoelectronic hybrid cable access, RJ45 supports PoE 30W output, to achieve "No Power Mode" from the server room to the terminal.
Ultra Long Distance Power Supply
Support PoF power supply, input voltage is 48V-57V, PoF transmission distance is 300 meters, breaking the 100 meter limit of PoE power supply.
Only one Power Port is Required
F100P can receive power and transmit data through an optoelectronic hybrid cable, it can also supply power to terminal devices through PoE (maximum power 30W), achieving no need to take power from the data center to the terminal, and the entire process is passive.
Port Speed Can be Set
You can limit the usage rate of different access ends by setting the port speed.
Smart Cloud Management
Directly managing devices through cloud platforms is simpler and more convenient.
| Item | HSGQ-F100P |
| User Interface | 1*GE RJ45 interface |
PoE+, supports up to 30W | |
| PoF PON Interface | GPON and EPON mode self-adaptation Interface mode: Optical-electric composite cable (PoF) |
GPON: Uplink 1.25Gbps /Downstream 2.5Gbps Transmit optical power: 0~4dBm Optical Power: -7dBm~-28dBm | |
EPON: uplink 1.25Gbps /downplink 1.25Gbps Transmit optical power: 0~4dBm Optical power: -7dBm~-27dBm | |
PoF input voltage: 48V-57V PoF transmission distance: 300m | |
| Ethernet | 1*10/100/1000M auto-negotiation |
| Transmission distance:100m | |
| Size | 120mm x 85mm x 28mm |
| Environment | Working temperature: -30°C~70°C |
| Operating humidity: 0%~85% (non-condensing) | |
| Storage temperature: -40°C~80°C | |
| Storage humidity: 5%~95% (non-condensing) | |
| Power Supply | PoF: 48V-57V, 0.25A |
| Power Consumption | <10W |
Adopts point-to-multipoint network topology, effectively collects andaggregates users' dispersed Ethernet services, and provides standard RJ45 Fast Ethernet interfaces on the user side.
Support lGMP multicast, effective use of broadband.
Multicast passthrough support.
Support vlan pass-through/tagging/translation/Qin-Q/trunk.
Provide remote management via OLT, supports local console management.
Support line loopback detection for user-side Ethernet interfaces.
Support IEEE 802.1q VLAN Protocol.
Support broadcast storm suppression.
Support lEEE802.3x flow control (full duplex).
Support lEEE 802.1p, CoS protocols.
Support WR, SP queue scheduling algorithm.
Support port speed limit.
Support -30°C~70°C operating environment.
Support IPv4 and lPv6.
Support cloud management.
Support PoF, power supply up to 30W.
