Fibre Channel SCSI technology is the physical foundation of SAN technology. When building a 32G SAN storage network, in addition to Fibre Channel switches, HBA optical network cards and other devices, 32G SFP28 FC optical modules and fiber jumpers are also required as the transmission carrier. Now, we will introduce the types and applications of 32G SFP28 FC single-mode optical modules.
1、32G FC SFP28 LR 10km(ES2313X-3LCD10)
It uses a hot pluggable SFP28 package, a dual fiber LC interface, a working wavelength of 1310nm, a DML laser and a PIN photodetector. It meets the SFP28 MSA and 32G fiber channel standards, and is backward compatible with the 8G/16G fiber channel standards. The maximum speed is up to 28.05Gbps. It can transmit up to 10km through the single-mode optical fiber OS2.
2、32GFC SFP28 ER 40km(ES2313X-3LCD40)
It adopts hot pluggable SFP28 package, dual fiber LC interface, operating wavelength of 1310nm, equipped with EML laser and APD photodetector. It complies with SFP28 MSA and 32G fiber channel standards, and can be backward compatible with 8G/16G fiber channel standards. The maximum speed is up to 28.05Gbps. It can transmit up to 40km through single-mode optical fiber OS2.
3、32GFC CWDM SFP28 10km(ES2Cxx3X-3LCD10)
It uses a hot pluggable SFP28 package, a dual fiber LC interface, an optional working wavelength of 1270nm-1610nm (interval of 20nm), and a CWDM DML laser and APD photodetector. It conforms to the SFP28 MSA and 32G fiber channel standards, and is backward compatible with the 8G/16G fiber channel standards. The highest speed rate is up to 28.05Gbps. It can transmit up to 10km through the single-mode fiber OS2.
4、32GFC DWDM SFP28 10km(ES2Dxx3X-3LCD10)
It uses a hot pluggable SFP28 package, a dual fiber LC interface, an optional working wavelength of C17-C61 (interval of 100Hz), and a DWDM EML laser and PIN photodetector. It complies with the SFP28 MSA and 32G fiber channel standards, and is backward compatible with the 8G/16G fiber channel standards. The maximum speed is up to 28.05Gbps. It can transmit up to 10km through the single-mode fiber OS2.
