SFP Single Mode Fiber BIDI Transceiver 1.25Gbps 10~20km

Specifications

Contact Us for a Quote
1.25G Single Mode

Product description

Product Features

● Uncooled Laser Diode with MQW Structure

● InGaAs PIN-TIA Photodiode Receiver

● Reach 20 km Transmission Distance on 9/125μm SMF

● BIDI Single Mode Transceiver SFP Footprint

● LC Or SC Optical Interface Are Optional

● Compliant With SFP MSA and SFF-8472

● Digital Diagnostic Monitoring Interface

● Single +3.3V Power Supply

● LVPECL Differential Inputs and Outputs

● LVTTL Signal Detection Output

● Compliant With ITU-T G.957

● Compliant With RoHS and Lead Free

● Metal Enclosure for Lower EMI

● Operating Case Temperature:

    Standard: 0 to +70°C

    Extend: -20 to +85°C

    Industrial: -40 to +85°C



Product Applications

Gigabit Ethernet

Fiber Channel

ATM/SONET/SDH/Switch/Router

Other Optical Transmission Systems


General Description

The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 20km transmission distance on 9/125μm SMF.

The transceiver consists of three sections: a FP/DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and DDMI control unit. All modules satisfy class I laser safety requirements.

The transceivers are compliant with the Small Form-Factor Pluggable (SFP)

Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
