An optical access network is an access network that uses light as the transmission medium, replacing copper wires and is used to access each home. The optical access network is composed of OLT (Optical Line Terminal, optical line terminal) and ONU (Optical Line Terminal) Network Unit, Optical Network Unit) and ODN (Optical Distribution Network, Optical Distribution Network) are composed of three parts; OLT and ONU are the core components of the optical access network. The core component of the optical access network. The schematic diagram of the optical access network is shown in the following figure:
The OLT is the core component of the optical access network, which is equivalent to a switch or router in a traditional communication network, and is also a multi-service providing platform. It is generally placed at the central office and provides an optical fiber interface for the user-oriented passive optical fiber network. Its main functions are:
•Uplink the upper layer network to complete the uplink access of the PON (Passive Optical Network, passive optical network) network.
• Through the ODN network (composed of optical fiber and passive optical splitter), it is connected to the ONU of the user-end equipment. Realize the functions of control, management and ranging of the ONU of the user terminal equipment.
ONU is a user-end device in an optical network. It is placed on the user-end and used in conjunction with the OLT to implement Ethernet Layer 2 and Layer 3 functions and provide users with voice, data and multimedia services. Its main functions are:
• Select to receive data transmitted by OLT.
• Respond to management commands issued by the OLT and adjust accordingly.
• Cache the user's Ethernet data and transmit it in the upstream direction in the transmission window assigned by the OLT.
• Other user management functions.
In short, OLT is like a commander, directing each ONU soldier, in order to provide low-cost and high-speed communication services, through light to connect us more closely together on earth, technology changes life.
