The 40G QSFP+optical module is a four channel small pluggable optical module with a transmission rate of 40Gbps. It can realize the interconnection between network devices (such as switches, routers, media converters and other similar devices) and optical cables or copper cables. Its structure is more compact than the CFP optical module, so it is more suitable for applications with large port density. The common 40G QSFP+optical modules can be divided into 40GBASE-SR4 optical module, 40GBASE-LR4 optical module, 40GBASE-ER4 optical module and 40G LR4 PSM optical module.
The interface of 40G SFP+SR4 optical module is MPO/MTP. It has four independent full duplex channels and is often used with multimode fiber. The transmission distance when used with OM3 fiber jumper is 100m, and the transmission distance when used with OM4 fiber jumper is 150m.
The interface of 40G QSFP+LR4 optical module is LC duplex, which has the advantages of high density, high speed, large capacity, low cost and low power consumption. It is generally used together with LC single-mode fiber jumper, and the transmission distance can be up to 10km.
The interface of 40G LR4 PSM optical module is MPO/MTP. Parallel Single Mode (PSM) is adopted. The MPO/MTP interface designed in four parallel ways is used. The transmission distance is 10km. It has the characteristics of high port density and low cost.
The 40G QSFP+ER4 optical module, like the 40G QSFP+LR4 optical module, is used together with LC single-mode fiber. The difference is that the 40G QSFP+ER4 optical module converts four input channels of 10G data into four CWDM optical signal channels, with the rate of each channel as high as 11.2 Gbps, and multiplexes them into a single channel for 40G optical transmission, which is mainly used for 40GBASE-ER4 Ethernet links, Infiniband QDR and DDR interconnects, and 40G telecom connections of clients. It can provide you with 40G QSFP+DAC high-speed cable, 40G AOC active optical cable, QSFP+optical module, MPO optical jumper and other transmission equipment required for 40G network cabling scheme.
