1.25G Multiple Mode

Product Features

● Uncooled Laser Diode with MQW Structure

● InGaAs PIN-TIA Photodiode Receiver

● 9/125μm SMF

● BIDI Single Mode Transceiver SFP Footprint

● LC Or SC Optical Interface Are Optional

● Compliant With SFP MSA and SFF-8472

● Digital Diagnostic Monitoring Interface

● Single +3.3V Power Supply

● CML Differential Inputs and Outputs

● LVTTL Signal Detection Output

● Compliant With ITU-T G.957

● Compliant With RoHS and Lead Free

● Metal Enclosure for Lower EMI

● Operating Case Temperature:

    Standard: 0 to +70°C

    Extend: -20 to +85°C

    Industrial: -40 to +85°C

Product Applications

● Fast Ethernet

● ATM/SONET/SDH

● Switch/Router

● Other Optical Transmission Systems

General Description

The SFP transceivers are high performance, cost effective modules supporting data-rate of 1250 Mbps and 20km transmission distance on 9/125μm SMF.

The transceiver consists of three sections: a laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and DDMI control unit. All modules satisfy class I laser safety requirements.

The  transceivers  are  compliant  with  the  Small  Form-Factor  Pluggable  (SFP) Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
