How to connect the multi -mode fiber jump line?

What is a multi -mode optical fiber jump line?

The multi -mode optical fiber jump is used as a jumping line from the device to the optical fiber wiring link. It has a thick protective layer and is generally used to connect the optical end machine and terminal box.

The main types of multimodular fiber:

Gigabit: 62.5/125um (OM1) Orange, 50/125um (OM2) Orange

Thousands: 50/125um (OM3) Lake Blue, 50/125um (OM4) purple and lake blue.

Among them, 62.5 and 50 represent the diameter of the fiber fiber core, and 125 represents the diameter of the glass bag. The lines of the multi -mode jump line are usually printed with the words "MM" or "OM3", "50/125", and "62.5/125".

Note: Because the core standards of single -mode fiber jump lines and multi -mode fiber jump lines are different, 9/125 and 50/125, 62.5/125, the wavelength of transmission is different, so single -mode fiber optic jump lines and multi -mode multi -mode The fiber jumping line cannot be connected to each other.

How to connect multi -mode fiber optic jump?

We know that multi -mode optical fiber jump lines are generally used in the case where the network (local area network) and transmission distance are short. Connect to the light -end machine, the light -ending machine can turn the light signal to the electrical signal we usually use. The multi -mode optical fiber jump line is connected to both ends. Generally, the optical fiber box is the ST head. The switch fiber -fiber module is LC head. The fiber transceiver is SC head.
